Technical features
1. Human-computer interaction,digital tube display
2. Operate steadily, low rate heat
3. The rate of rise and fall is adjustable
4. Have slow start and slow stop function
5. Turn crossing protection, Prevents motor burn out
Specifications
| Model | GKBP-50 | GKBP-80 |
| Input voltage | 220V/50Hz | |
| Rated power | 450W | 600W |
| Starting torque | 55N.m | 85N.m |
| Maximum door weight | 25m² | 40m² |
| Noise | ≤55db | |
| Mode of manual chain | Universal chain style | |
| Max limited journey | 19 rounds rotation the output shaft | |
| Ambient temperature | (-20℃-45℃) (-40℃ Can be customized) | |
| Limit | Absolute value encoder | |
| Start State | Slow start slow stop | |
| Load Rouning Time | 18min | |
Our service:
1. Logo printing on products;
2. Customized color box or carton;
3. Any your ideas on products we can help you to design and put it into production.
