100W Barrier Gate System , IP54 Parking Garage Barrier

50 SETS
MOQ
Negotiable
Price
100W Barrier Gate System , IP54 Parking Garage Barrier
Features Gallery Product Description Request A Quote
Features
Specifications
Power Supply: AC110V-264V/47-63HZ
Motor Power: 100W
Machine Case Thickness: 2mm
No-load Speed: 3000r/min
Control Voltage: 24VDC/max.300mA
Service Life: 5-10 Million Times
Motor Speed Without Load: 3000r/min
Driving Method: Servo Motor+Planetary Reducer
Protection Level: IP54
High Light:

100W Barrier Gate System

,

24VDC Barrier Gate System

,

IP54 Parking Garage Barrier

Basic Infomation
Place of Origin: China
Brand Name: SONGRUI
Certification: CE
Model Number: BG5025
Payment & Shipping Terms
Delivery Time: 5-8 WORK DAYS
Payment Terms: T/T
Product Description

Servo Barrier Gate Intenrated Machine Barrier Gate System

Features:

1. 485 communication interface makes it easy to remote control the barrier gate and get the state feedback.

2. Through setting the DIP switch, users can choose operation mode and operation parameters, which can meet customer’s requirements for different functions to maximum.

3. High-sensitivity Auto-reverse function which can prevent incorrect operation and other crash or hitting accidents.

4. High-strength precision cast steel machine case, with outdoor metal powder electrostatic spraying surface treatment, waterproof and dustproof, IP class 54.

5. Four lines two colors LED display screen, users can input the contents to display.

6. HD license plate recognition camera with motorized zoom lens, one button adjustment, camera capturing distance far or near among 3M-8M.

7. Support offline function, for fixed user parking lot, no PC required.

8. The camera supports IP network interface, RS485 data transmission, and multiple trigger modes.



Product Specification:

Model BGY3009 BG4014 BG5025 BG6035
Boom Length ≤ 3m ≤ 4m ≤ 5m ≤ 6m
Open/Close Time 0.9 sec 1.4 sec 2.5 sec 3.5 sec
Working Temperature -40~+70 ℃
Relative Humidity ≤ 90%
Insulation Class F
Protection Class IP54
Power Supply AC110-264V/47-63Hz
Barrier Gate Working Voltage DC24V
Motor Power 100w
No-load Speed 3000r/min
Service Life 5-10 million times
Driving Method Servo Motor + Planetary Reducer
Machine Case Thickness 2mm
Machine Case Surface Treatment Outdoor metal powder electrostatic spraying
Remote Control Distance ≤100m (wide open area, sunny weather)
Running Noise <60dB
License Plate Recognition Camera Pixel 200W
Network TCP/IP Port
Working Voltage DC12V
Resolution 1280×960
LED Display Screen Display Size 304×304mm
Resolution 64×32
Specification F3.75 double colors, four lines display
Scan Method 1/16
Interface Type 08
Working Voltage DC12V
Filling Light Power 15W
Working Voltage AC220V
Angle 45º
Vehicle Detector Working Voltage AC220V
Working Frequency 20 KHz ~170 KHz
Reaction Time 10ms
Sensitivity 9 levels adjustable
Machine Case Size(W×D×H) 370 × 515 × 1580mm
Net Weight 60kg
