Solar System Sliding Gate Motor for 800kg AC Motor sliding gate opener Electric Gate Operator DKC800AC
The DKC800AC gate opener designed for residential use, weight up to 800Kg and operating distance up to 8 meters.
Product features:
Standard Unit:
Main technical parameters:
Unit Model
|
DKC500DC
|
DKC800DC
|
DKC500AC
|
DKC800AC
|
Power supply
|
AC220V/50Hz; AC110V/60Hz
|
|||
Maximum gate weight
|
500KG
|
800KG
|
500KG
|
800KG
|
Motor Power
|
DC24V/150
|
DC24V/170
|
280W
|
380W
|
Output torque
|
14N.m
|
18N.m
|
14N.m
|
18N.m
|
Output Shaft Height | 46mm | |||
Work duty
|
S2 20min
|
|||
Limit switch
|
Magnetic limit switch
|
Magnetic limit switch or spring limit switch | ||
Gate moving speed
|
11-13m/min
|
16-18m/min
|
13m/min
|
13m/min
|
Remote control range
|
≥30md
|
|||
recording of up remote controls
|
25
|
|||
Frequency
|
433.92MHz
|
|||
Noise
|
≤58db
|
|||
Working temperature
|
-20℃~+70℃
|
|||
Backup Battery
|
Optional
|
/
|
||
Driving Mode
|
Gear
|
Gear
|
Gear
|
Gear
|
Package Weight
|
11KG
|
11KG
|
