380V 2000KG 750W AC Motor Sliding Driveway Gate Opener

50 SETS
MOQ
Negotiable
Price
380V 2000KG 750W AC Motor Sliding Driveway Gate Opener
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Sliding Gate Opener
Model Number: PY2000ACS
Power Supply: 380V/50Hz
Motor Power: 750W
Gate Moving Speed: 10-12m/min
Maximum Weight: 2000Kg
Limit Switch: Spring Limit Switch / Magnetic Limit Switch
Remote Control Mode: Single Button Mode / Three Button Mode
High Light:

380V Sliding Driveway Gate Opener

,

2000KG Sliding Driveway Gate Opener

,

750W sliding driveway gate motor

Basic Infomation
Brand Name: SONGRUI
Model Number: PY2000ACS
Certification: CE
Place of Origin: China
Payment & Shipping Terms
Payment Terms: T/T
Supply Ability: 10000 Set/Sets per Month
Delivery Time: 5-8 WORK DAYS
Packaging Details: 340*290*373cm
Product Description



380V 2000KG 750W AC Motor Sliding Driveway Gate Opener 0

380V 2000KG AC Motor Sliding Driveway Gate Opener​

The gate opener designed for commercial and industrial use, weight up to 2000Kg and operating distance up to 12 meters.

Product features:
1. Oil lubrication, generous appearance, heavy duty.
2. Compact strucretu, cost-effective.
3. AC motor with built-in control unit.
4. Keypad / single button interface.
5. Alarm lamp, photo beam & safty beam interface.
6. User can select auto-close function.
7. Soft start and slow stop. (Smart version)
8. Auto-reverse function when hitting obstacle during closing. (Smart version)
9. Manual key release design for emergency purposes.



Main technical parameters:

Warranty
1 Year
After-sale Service
Online technical support
Project Solution Capability
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
Application
Apartment
Design Style
Modern
Model Number
PY2000ACS
Model
PY2000ACS
Power supply
AC 380V
Motor power
750W
Output Torque 40N.m
Output Shaft Height 56mm
Gate moving speed
10-13m/min
Maximum weight of gate
2000Kg
Remote control distance
≥30m
Recording of Up Remote  25
Remote Frequency  433.92NHz
Remote control mode
Single button mode / Three button mode
Limit switch
Spring limit switch / Magnetic limit switch
Work Duty  S2 20min
Working Noise  ≤58dB
Working temperature
-20°C ~ +70°C
  Driving Mode  Gear
Package weight
17.50Kg

380V 2000KG 750W AC Motor Sliding Driveway Gate Opener 1380V 2000KG 750W AC Motor Sliding Driveway Gate Opener 2380V 2000KG 750W AC Motor Sliding Driveway Gate Opener 3
380V 2000KG 750W AC Motor Sliding Driveway Gate Opener 4380V 2000KG 750W AC Motor Sliding Driveway Gate Opener 5
