Automatic Door Opener Double 10m 36V Safety Beam Sensor

50 SETS
MOQ
Negotiable
Price
Automatic Door Opener Double 10m 36V Safety Beam Sensor
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Safety Beam Photocell Sensor
Type: YS130
Usage: Position Sensor
Theory: Optical Sensor
Power Supply: AC/DC 12-~36V
Mounting Height:: Max 10m
Relay Output: NO,NC
High Light:

36V Safety Beam Sensor

,

10M 36V Safety Beam Sensor

,

10M 36V door beam sensor

Basic Infomation
Place of Origin: China
Brand Name: SONGRUI
Certification: CE
Model Number: YS130
Payment & Shipping Terms
Delivery Time: 5-8 WORK DAYS
Payment Terms: T/T
Supply Ability: 10000 Set/Sets per Month
Product Description

Double Type Safety Beam Photocell For Automatic Door Opener



Features:

1. Adopt microcomputer control technology, high integration with high stability. International optical lens design with good focus quality, controlled angle is rational,easy to be installed.

2. Far transmit distance with strong, anti-interference ability.

3. Adopting receiving filter,decoding,amplification system of German technology.

4. Effective solution to anti-interference of natural daylight.

5. Emission electric eye adopts low-power consumption design with far transmit distance.

6. Emission contact and receive contact output separtely with shielding line.

7. When the signal light be blocked, N.O or N.C,contact can be flexibly chosen. With AC 12-28V/DC 12-36V power input.



Product Specification:

Power supply:

AC 12-28V/DC12-36V

Static current:

25mA

Action current:

40mA

The maximum transmit distance

10m

NO or NC contact:

Done by NO/NC contact selection

Beam:

Single beam or double beam

Working Environment temperature:

-42℃~45℃

Working environment humidity:

10~90%RH

Appearance dimensions(controller):

123(L)X50(W)X32(H)mm

Appearance dimensions(Magic eye head):

19(L)X13(D)

Total Weight:

(Single beam) 220G



Our service:

Welcome OEM&ODM orders

1) Logo printing on products;
2) Customized color box or carton;
3) Any your ideas on products we can help you to design and put it into production.

Automatic Door Opener Double 10m 36V Safety Beam Sensor 0Automatic Door Opener Double 10m 36V Safety Beam Sensor 1Automatic Door Opener Double 10m 36V Safety Beam Sensor 2Automatic Door Opener Double 10m 36V Safety Beam Sensor 3

Automatic Door Opener Double 10m 36V Safety Beam Sensor 4Automatic Door Opener Double 10m 36V Safety Beam Sensor 5
