Main technical parameters:
Unit Model | PY300DC | PY300DCL |
Power Supply | AC220V/50Hz; AC110V/60Hz | |
Maximum Gate Weight | 300kg | |
Motor Power | 24VDC, 100W | |
Output Torque | 8N.m | |
Output Shaft Height | 46mm | |
Limit Switch | Electronic limit switch | |
Gate Moving Speed | 13m/min | |
Remote Control Range | ≥30m | |
Recording of Up Remotes | 25 | |
Frequency | 433.92MHz | |
Work Duty | S2 20min | |
Noise | ≤60db | |
Working Temperature | -20℃~+50℃ | |
Backup Battery | 24V 4.5Ah | |
Driving Mode | Gear | Chain |
Package Weight | 11.50kg | 19.00kg |
Our service:
Welcome OEM&ODM orders
1. Logo printing on products;
2. Customized color box or carton;
3. Any your ideas on products we can help you to design and put it into production.
